Product Introduction:
Top-Con carbon-carbon plate is a short-fiber reinforced carbon-carbon laminate produced by uniformly dispersing chopped carbon fibers, resin impregnation, compression molding, followed by liquid-phase impregnation densification, high-temperature purification, and machining.
Production Process:
Short fiber plate blank → Machining → Final assembly
Product Advantages:
Lightweight, high corrosion resistance, single-sheet thickness achievable down to 1.7mm, 20%+ production efficiency improvement, lightweight for easy handling, low void rate.
|
Density g/cm3 |
Bending Strength MPa |
Tensile Strength Mpa |
Compressive Strength Mpa |
Interlayer Shear Strength Mpa |
Resistivity um·Ω |
Thermal Conductivity (Vertical Direction) W/m·K |
Ash Content ppm |
Graphitization Temperature ℃ |
Size mm |
| 1.4 | 160 | 140 | 125 | 16 | 20 | 8 | ≤200 | ≥2000 | l≤2600 |
The above data are representative values and are not guaranteed values.
